Edelmann & Associates, Inc. is the Wilden distributor for Wilden air operated diaphragm pumps in Minnesota, Western Wisconsin, North Dakota, and South Dakota. Wilden AODD pumps are available in metal or plastic, bolted or clamp band construction, with several air distribution systems such as the new PRO-FLO™ SHIFT,  PRO-FLO®, ACCU-FLO™, and TURBO-FLO™ pumps.  The newest series, Pro-Flo SHIFT, saves up to 60% in Air Consumption with up to 34% great flow rate than competitors.  Plus it’s 6 year warranty is unrivaled.  Wilden Pumps are Simple. Reliable. Efficient.

Wilden AODD pumps provide numerous unique benefits in all types of applications and markets, such as:

  • Self Priming
  • Shear Sensitive
  • Dry-Run Capable
  • Submersible
  • Portable
  • High Suction Lift

  • Variable Flow and Pressure
  • Viscous and Non-Viscous Product Transfer
  • Ease of Operation and Maintenance
  • Corrosion Resistant
  • No Heat Generation
  • Longest Mean Time Between Failure (MTBF)

Watch Wilden Videos

Wilden AODD Positive Displacement Pumps

The PRO-FLO SHIFT represents a significant breakthrough in energy efficiency with savings up to 60% air consumption and 34% greater flow rates compared to competitors.

Wilden’s PRO-FLO™ series of pumps are anti-freezing, and feature on/off reliability, lube-free operation, and a non-stalling unbalanced air valve.

The ACCU-FLO™ pump offers superior solenoid operated on/off reliability, lube-free operation, and simple installation. They offer excellent metering control with a direct electrical interface, and various voltage options.

Wilden’s TURBO-FLO™ pumps are an economical choice with low initial cost and proven technology. They feature a reliable metallic air distribution system, and are easy to maintain with very few replacement parts.



Wilden Pumps Selection

Wilden Air Operated Diaphragm Pumps primary types are listed below.

Featured:  Pro-Flo Shift

Wilden’s Pro-Flo SHIFT is part of a new generation of air distribution systems (ADS) that have been designed to eliminate overfilling in AODD pump operation.  This pump design restricts the air flow into the air chamber near the end of each pump stroke so that only enough air is introduced to keep the pumping process going. This is accomplished through the incorporation of an air control spool that automatically optimizes air consumption and eliminates overfilling of the air chamber with no reduction in flow rate.

Designed off the same basic design principles as the tried and true Pro-Flo Series which feature:

  • Unbalanced spool preventing stalling
  • Simple pilot spool to trigger which air chamber is filled
  • Minimum moving parts (less wear)
  • Tight tolerances to eliminate lost air
  • Up to 60% Air Savings at existing flow rates
  • Reduced total cost of ownership
  • Ease of maintenance
  • Ability to be used in harsh operating environments
  • No electricity required

Wilden Savings Calculator

Download the Wilden Savings Calculator (this is an excel file with formulas for your use).

pro-flo-shift-energy-savings-calculator_xlsx

Advanced Metal Pumps

  • Bolted configuration
  • Available in aluminum, stainless steel, alloy C
  • ANSI flanges or NPT
  • 1" - 3" ports available
  • Flow rate to 279 gpm
Wilden-Advanced-Metal-Pump-aodd

Advanced Plastic Pumps

  • Bolted Configuration
  • Available in polypropylene, PVDF and PTFE PFA
  • ANSI flanges or NPT
  • 1/4" - 3" ports available
  • Flow rates to 232 gpm
Wilden-Advanced-Plastic-Pumps-Proflo-aodd

Original Plastic Pumps

  • Clamped configuration
  • Available in polypropylene, PVDF, and PTFE PFA
  • 1/4" - 2" ports available
  • Flow rates to 170 gpm
Wilden-Original-Plastic-Pump-aodd

Original Metal Pumps

  • Clamped configuration
  • Available in aluminum, cast iron, stainless steel and alloy C
  • NPT connections
  • 1/4" - 3" ports available
  • Flow rates to 245 gpm
Wilden-aodd-Original-Metal-Pumps

Specialty Pumps

  • Saniflo Sanitary Series
  • High Pressure Pumps
  • Flap Valve Pumps
Wilden-aodd-Saniflo-FDA-Sanitary-Pump

Wilden Genuine OEM Pump Parts & Accessories

  • Diaphragms
  • Pistons
  • Valve Balls, Seats & O-rings
  • Pulsation Dampeners

Information Source Wilden
